Product Details:
|
Product Name: | Laser Welded Diamond Saw Blade | Manufacturing Process: | Laser Welding |
---|---|---|---|
Outer Diameter: | 600mm | Application: | Cutting Reinforced Concrete |
Inner Hole: | 25.4mm, 50mm Or As Your Request | Segment Thickness: | 4.4mm |
Segment Height: | 10/12/15mm | Color: | Clear Or As Your Request |
HS Code: | 8202391000 | ||
Highlight: | concrete diamond blade,concrete circular saw blade |
1. Description of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete
600mm diamond concrete saw blades is mainly used for the situations which contained reinforced concrete, like cutting new and old road expansion joints and bridge parapet ripper dressing.
Design different segment formula for different power machines, different hardness, different wear resistance, etc. Apply to different construction materials cutting.
Well exported to Australia and Asia, Europe, America, Africa, market.
2. Feature of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete
1) Fast speed, high efficiency for cutting reinforced concrete structure.
2) The kerf is very smooth and flat, surface is very pretty.
3) Concrete cutting is no vibration, have no influence for previous structure.
4) Reinforced concrete cutting is no dust, low noise, it is a good environment.
5) Well precision construction.
3. Specification of 600mm Diamond Saw Blade with Good Sharpness for Reinforced Concrete
Diameter:600mm
Segment thickness:4.4mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm as your request
Inch | Diameter (mm) |
Teeth length (mm) |
Teeth thickness (mm) |
Teeth height (mm) |
Teeth number (nos) |
24" | 600 | 40 | 4.4 | 10 | 42 |
24" | 600 | 40 | 4.4 | 12 | 42 |
24" | 600 | 40 | 4.4 | 15 | 42 |
Other size Concrete Saw Blade we could do as following
Inch | Diameter (mm) |
Teeth length (mm) |
Teeth thickness (mm) |
Teeth height (mm) |
Teeth number (nos) |
4" | 105 | 32 | 2.2 | 7/10/12 | 8 |
4.5" | 115 | 31 | 2.2 | 7/10/12 | 9 |
5" | 125 | 31 | 2.2 | 7/10/12 | 10 |
6" | 150 | 34 | 2.2 | 7/10/12 | 11 |
7" | 180 | 34 | 2.4 | 7/10/12 | 14 |
8" | 200 | 40 | 2.4 | 7/10/12 | 13 |
9" | 230 | 37 | 2.6 | 7/10/12 | 16 |
10" | 250 | 40 | 2.6 | 10/12/15 | 16 |
12" | 300 | 40 | 3.0 | 10/12/15 | 20 |
14" | 350 | 40 | 3.2 | 10/12/15 | 24 |
16" | 400 | 40 | 3.4 | 10/12/15 | 28 |
18" | 450 | 40 | 3.6 | 10/12/15 | 32 |
20" | 500 | 40 | 4.0 | 10/12/15 | 36 |
26" | 650 | 40 | 4.4 | 10/12/15 | 42 |
28" | 700 | 40 | 5.0 | 10/12/15 | 40 |
4. Packing and Shipping
Each 24" laser saw blade is packed in white box, then 5pcs put in an export standard carton, gross weight per carton is limited within 45kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
