535mm Diamond Cutting Blades For Concrete with Good Sharpness

535mm Diamond Cutting Blades For Concrete with Good Sharpness
535mm Diamond Cutting Blades For Concrete with Good Sharpness 535mm Diamond Cutting Blades For Concrete with Good Sharpness

Large Image :  535mm Diamond Cutting Blades For Concrete with Good Sharpness

Product Details:
Place of Origin: China
Brand Name: Johnson Tools
Certification: SGS, GB
Model Number: 535mm
Payment & Shipping Terms:
Minimum Order Quantity: 50 pcs
Price: Negotiate
Packaging Details: white or colored package
Delivery Time: 15-35days
Payment Terms: Western Union, L/C, T/T,PayPal
Supply Ability: 1000pcs per month

535mm Diamond Cutting Blades For Concrete with Good Sharpness

Description
Outer Diameter: 535mm Center Hole: 25.4mm, 50mm As Your Request
Segment Thickness: 4mm Segment Height: 10/12/15mm
Other Size: 4"/4.5"/5"/6"/7"/8"/9"/10"/12"/14"/16"/18"/20"/24"/26"/28"/30"
High Light:

concrete diamond blade

,

circular saw concrete blade



1. Description of 535mm Laser Saw Blade with Good Sharpness for Cured Concrete Cutting



535mm diamond concrete saw blade is the professional diamond tools which installed on handheld power saws, walk behind concrete saws, road cutting machine for cutting cured concrete structures, road construction. It has a good cutting ability, static non-destructive, high efficiency, no construction dust and other characteristics.
Well exported to USA, UK, Peru, Mexico, Sweden, Iceland, Poland, Denmark, Croatia, Bulgaria, Italy, France, Spain, Norway, Netherland, Malta, Singapore, UAE, India, Australia, South Africa etc. Quality is well accepted by the customers.




2. Specification information of 535mm Laser Saw Blade with Good Sharpness for Cured Concrete Cutting



Diameter:535mm
Segment thickness:4.0mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm as your request



Inch Diameter
(mm)
Teeth length
(mm)
Teeth thickness
(mm)
Teeth height
(mm)
Teeth number
(nos)
21" 535 40 4.0 10 36
21" 535 40 4.0 12 36
21" 535 40 4.0 15 36


Other size Concrete Saw Blade we could do as following



Inch Diameter
(mm)
Teeth length
(mm)
Teeth thickness
(mm)

Teeth height
(mm)

Teeth number
(nos)
4" 105 32 2.2 7/10/12 8
4.5" 115 31 2.2 7/10/12 9
5" 125 31 2.2 7/10/12 10
6" 150 34 2.2 7/10/12 11
7" 180 34 2.4 7/10/12 14
8" 200 40 2.4 7/10/12 13
9" 230 37 2.6 7/10/12 16
10" 250 40 2.6 10/12/15 16
12" 300 40 3.0 10/12/15 20
14" 350 40 3.2 10/12/15 24
16" 400 40 3.4 10/12/15 28
18" 450 40 3.6 10/12/15 32
20" 500 40 4.0 10/12/15 36
24" 600 40 4.4 10/12/15 42
26" 650 40 4.4 10/12/15 42
28" 700 40 5.0 10/12/15 40
30" 750 40 5.0 10/12/15 46



3. Related products



The following is our company well exported to Chile, Uruguay etc.

350mm Laser Saw Blade, Segment Size: 40x3.2x10mm, Center hole: 25.4mm,slot: key and U



535mm Diamond Cutting Blades For Concrete with Good Sharpness 0



535mm Diamond Cutting Blades For Concrete with Good Sharpness 1



4. Packing and Shipping



If there is steel discs in our stock, normally shipment within 10-15days. If not, around 25-30days.



Our professional shipping agent or clients specified shipping agent.



By air, by sea, by land, by courier, etc.



535mm Diamond Cutting Blades For Concrete with Good Sharpness 2
